Sensor Length
LIN100F: 14.3 cm
LIN100M: 19.9 cm
LIN200F: 14.3 cm
LIN200M: 19.9 cm
Sensor Length
14.3 cm
19.9 cm
14.3 cm
19.9 cm
Mass Range
LIN100F: 100 amu
LIN100M: 100 amu
LIN200F: 200 amu
LIN200M: 200 amu
Mass Range
100 amu
100 amu
200 amu
200 amu
Detector Type
LIN100F: FC
LIN100M: EM
LIN200F: FC
LIN200M: EM
Detector Type
FC
EM
FC
EM
Sensitivity (FC)
LIN100F: 3E-4 amps/Torr
LIN100M: 3E-4 amps/Torr
LIN200F: 3E-4 amps/Torr
LIN200M: 3E-4 amps/Torr
Sensitivity (FC)
3E-4 amps/Torr
3E-4 amps/Torr
3E-4 amps/Torr
3E-4 amps/Torr
Sensitivity (EM)
LIN100F: N/A
LIN100M: 500 amps/Torr
LIN200F: N/A
LIN200M: 500 amps/Torr
Sensitivity (EM)
N/A
500 amps/Torr
N/A
500 amps/Torr
Min. Detectable Partial Pressure (3)
LIN100F: 2.6E-12 Torr
LIN100M: 1.5E-14 Torr
LIN200F: 2.6E-12 Torr
LIN200M: 1.5E-14 Torr
Min. Detectable Partial Pressure (3)
2.6E-12 Torr
1.5E-14 Torr
2.6E-12 Torr
1.5E-14 Torr
Max. Sensor Operating Temp. (FC)
LIN100F: 200°C
LIN100M: N/A
LIN200F: 200°C
LIN200M: N/A
Max. Sensor Operating Temp. (FC)
200°C
N/A
200°C
N/A
Max. Sensor Operating Temp. (EM)
LIN100F: N/A
LIN100M: 150 °C
LIN200F: N/A
LIN200M: 150 °C
Max. Sensor Operating Temp. (EM)
N/A
150 °C
N/A
150 °C
Filament Type Option
LIN100F: Dual Y2O3/Ir filaments /Dual Tungsten filaments
LIN100M: Dual Y2O3/Ir filaments /Dual Tungsten filaments
LIN200F: Dual Y2O3/Ir filaments /Dual Tungsten filaments
LIN200M: Dual Y2O3/Ir filaments /Dual Tungsten filaments
Filament Type Option
Dual Y2O3/Ir filaments /Dual Tungsten filaments
Dual Y2O3/Ir filaments /Dual Tungsten filaments
Dual Y2O3/Ir filaments /Dual Tungsten filaments
Dual Y2O3/Ir filaments /Dual Tungsten filaments
Resolution (1)
LIN100F: <1 amu Wide
LIN100M: <1 amu Wide
LIN200F: <1 amu Wide
LIN200M: <1 amu Wide
Resolution (1)
<1 amu Wide
<1 amu Wide
<1 amu Wide
<1 amu Wide
Temperature Coefficient (2)
LIN100F: <1% per °C
LIN100M: <1% per °C
LIN200F: <1% per °C
LIN200M: <1% per °C
Temperature Coefficient (2)
<1% per °C
<1% per °C
<1% per °C
<1% per °C
Zero Blast (@ mass 2)
LIN100F: <100 ppm
LIN100M: <100 ppm
LIN200F: <100 ppm
LIN200M: <100 ppm
Zero Blast (@ mass 2)
<100 ppm
<100 ppm
<100 ppm
<100 ppm
Max. Operating Pressure
LIN100F: 5E-4 Torr
LIN100M: 5E-4 Torr
LIN200F: 5E-4 Torr
LIN200M: 5E-4 Torr
Max. Operating Pressure
5E-4 Torr
5E-4 Torr
5E-4 Torr
5E-4 Torr
Max. Bakeout Temp.
LIN100F: 300 °C
LIN100M: 300 °C
LIN200F: 300 °C
LIN200M: 300 °C
Max. Bakeout Temp.
300 °C
300 °C
300 °C
300 °C
Power Input
LIN100F: 20-30 V (dc)
LIN100M: 20-30 V (dc)
LIN200F: 20-30 V (dc)
LIN200M: 20-30 V (dc)
Power Input
20-30 V (dc)
20-30 V (dc)
20-30 V (dc)
20-30 V (dc)
